| MODEL | EN/HL-45EZ | EN/HL-50EZ | EN/HL-55EZ |
| FILM WIDTH (mm) | 300-600 | 300-800 | 400-1000 |
| FILM THICKNESS(mm) | HD:0.009-0.15 LD:0.02-0.15 | HD:0.009-0.05 LD:0.02-0.10 | HD:0.009-0.10 LD:0.02-0.13 |
| MAX.EXTRUSION OUTPUT(kg/hr） | HD:30-45 LD:40-50 | HD:35-50 LD:50-60 | HD:40-70 LD:60-80 |
| SCREW DIAMETER | φ45 | φ50 | φ55 |
| SCREW L/D LENGTH | 30:1 | ||
| MAIN MOTOR(Kw) | 15 | 18.5 | 22 |
| DIE SIZE | φ60/80 | φ80/100 | φ100/120 |
| OVERALL DIMENSION(L×W×H) | 5.0×2.0×4.5m | 5.0×2.2×4.7m | 5.5×2.5×5.2m |
